Structures

This lesson introduces how to create another very common data type: structures (also called records or cards). Structures allow storing a fixed number of data of different types in a single variable and accessing any of them directly through their name. Although tuples also share this purpose, structures are more flexible because they are mutable and accesses are through an identifier rather than a number.

Introduction

A structure is a collection of related data stored in one place, as a whole. Each piece of data in a structure is called a field and has a name and a type. For example, a point could be described with a structure with two fields representing its X and Y coordinates. And a circle could be described with a structure with two fields: a point for its center and a float for its radius. Similarly, a structure to store information about a worker could store their name, address, and birth date, which would be a value of another structure for storing dates.

It is easy to imagine structures as form templates: In a form template, there are different fields, each with a name and a type. Each user will fill out the form template with their own data. For example, this is a form for booking a hotel room:

You can see there are fields for the client's name, their email address, the type of room, the number of guests, the arrival and departure dates... Each of these fields' values can be of different types: text for name and email, integer for number of guests, dates for arrival and departure dates, boolean for whether pickup is needed or not...

Records differ from lists and tuples in that their number of values is fixed, each field has a name instead of a position, and each field can be of a different type.

Declaration and use of structures

To declare a structure in Python we will use dataclasses; there are other ways to do it but this seems the most versatile to start with. This would be a structure corresponding to the information of a movie:

from dataclasses import dataclass

@dataclass
class Movie:
    identifier
    title
    director
    year
    black_and_white

This code snippet declares a new type Movie as a structure containing fields for its identifier (an integer), its title and director (two strings), the production year (another integer), and a boolean indicating whether it is black and white or not. The title of a movie is stored in its title field.

Structures are defined inside classes, a Python construct that has many more applications than what we will see for now. Also, for these classes to have some cool properties, they must be annotated with @dataclass, which must be imported from the standard module dataclasses. Inside the class, each field has a name and a type annotation, as if declaring a variable.

Once a structure is defined, variables of that type can be created. Look at this example:

p1 = Movie(
    1001,
    "Star Wars IV",
    "George Lucas",
    1977,
    False,                  # this last comma is optional
)

p2 = Movie(
    1234,
    "The Kid",
    "Buster Keaton",       # incorrect: should be "Charlie Chaplin"
    1921,
    True,
)

The variables p1 and p2 have been initialized by using the name of their type as if it were a function (in fact, this is called a constructor), and providing the list of values for their fields, in the same order in which they were declared. Obviously, these values must be compatible with the declared fields.

Once created, the variables p1 and p2 are now of type Movie:

>>> type(p1)
<class '__main__.Movie'>

The only operation that can be done on a variable of structure type is selecting one of its fields. This is done by writing the variable name, a dot, and the field name.

For example, this snippet says whether p1 is earlier or later than p2:

if p1.year < p2.year:
    print("Earlier")
else:
    print("Later")

And this piece of code corrects the director of The Kid:

p2.director = "Charlie Chaplin"

In the first case, the year fields were selected to query them. In the second case, the director field of p2 was selected to modify it.

In Python, structures are also objects, like lists. Therefore, structures are manipulated through references, with the advantages and risks that this entails.

There are two fundamental differences between tuples and structures:

1. While tuples had fields identified by numbers starting at zero, structures have their fields identified by names. When there are many fields, this makes manipulation easier (no need to remember that 3 represents the title).

2. While tuples were immutable, changing the values of structure fields is possible (and common).

And that's it! There's nothing more: Structures are very simple to declare and use. Below we give some applications and see more details.
