Application: Easy Octagons

This lesson shows a possible solution for the problem P87198 (Easy Octagons) from Jutge. The solution uses actions and employs top-down design, a programming methodology that breaks down a complex problem into subproblems less complex than the original.

Exercise P87198 (Easy Octagons)

The statement is simple: You need to write a program that for each given n prints "an octagon of size n", following the pattern shown in the examples. For example, when n is 2, you should print

 XX
XXXX
XXXX
 XX

and when n is 3, you should print

  XXX
 XXXXX
XXXXXXX
XXXXXXX
XXXXXXX
 XXXXX
  XXX

How can we solve this?

First of all, we can write the main program directly and without hesitation like this:

from yogi import tokens

def main():
    for n in tokens(int):
        write_octagon(n)
        print()

if __name__ == '__main__':
    main()

Easy, right? We simply wrote the usual code to read a sequence of integers and, for each of them, we delegated the task of printing the corresponding octagon to an action write_octagon that we leave for later. We also add a newline after each octagon, as the statement requires.

This way we have a small and simple main, without any complexity that might lead us to make mistakes. Also, we have encapsulated the idea of printing an octagon in an action, a highly recommended idea, since it provides simplicity, structure, and will allow us to reuse the code to draw this figure if we ever need it in the future.

Now, we only have to worry about printing a single octagon, and we must do it inside the action write_octagon, which receives an integer with its size. Its header is thus:

def write_octagon(n):
    """Action that prints an octagon of size n."""

To define the body of this action, from the pattern in the examples, we can see that an octagon is decomposed into three parts: the upper part, the middle part, and the lower part:

  XXX      upper part
 XXXXX     upper part
XXXXXXX    upper part
XXXXXXX    middle part
XXXXXXX    lower part
 XXXXX     lower part
  XXX      lower part

Thus, we choose to define write_octagon using these three parts:

def write_octagon(n):
    """Action that prints an octagon of size n."""
    write_upper_part(n)
    write_middle_part(n)
    write_lower_part(n)

Again, we delegate the task of printing an octagon to three other actions that we define below:

def write_upper_part(n):
    for i in range(n):
        write_line(n - i - 1, n + 2 * i)

def write_lower_part(n):
    for i in range(n - 1, 0, -1):
        write_line(n + 2 * i, n - i - 1)

def write_middle_part(n):
    for i in range(n - 2):
        write_line(0, 3 * n - 2)

Here, once again, we have introduced a new action write_line that is used by the three actions. The purpose of write_line(n, m) is to print a line with n spaces followed by m X's. We leave the choice of the precise values for the loop starts and ends for you to think about and work on.

Finally, the code for write_line is this:

def write_line(n, m):
    """Action that prints n spaces, m X's, and a newline."""
    print(' ' * n + 'X' * m)

Notice that to solve this problem we used the top-down design methodology, so we decomposed the complexity of the problem from the most general level to the most concrete. The following diagram shows the relationship of the actions with each other:
